Nachi 100% Original 1061121 7/8 118° 10-1/2 OAL M35 5% Cobalt Coolant Fed Drill 1 pcs
Original price was: $351.43.$117.14Current price is: $117.14.
- For drilling operations where a coolant or oil delivery system is available.
- For drilling holes in a variety of normal steels, cast iron, and other ferrous and non-ferrous metals and alloys.
- Suitable for a variety of drilling applications and conditions.
- Right hand (clockwise rotation) cutting direction.
- Made with two holes through their length to feed fluid to the drill.
- Normal spiral and a normal 118° drill point angle, notch point, and a rolled heel for better coolant delivery and chip ejection.
- Standard straight shanks that correspond to drill diameter.
- Taper length drills have flutes proportional to length.
- Manufactured from M35 cobalt.
- Cylindrically ground.
- Constant heavy duty web for greater strength.
- Shank coolant entry to suit industry standard toolholders.
| Brand | NACHI |
|---|---|
| Size Type | Fractional |
| Size | 7/8" |
| Drill Point Angle | 118° |
| Tool Material | M35 5% Cobalt |
| Finish Coating | Bright |
| Shank Diameter | 7/8" |
| Overall Length | 10-1/2" |
| Type | Taper Length |
| Morse Taper | None |
| Flute Length | 7" |
| First Choice For: | Stainless Steel |
| Model # | 1061121 |
| Point Sharpening Type | Notched Point |
| Drill Grade | Heavy Duty |
| Drill Type | Coolant Fed |
| Flute Shape | Helical |
| Manufacturing Method | Cylindrically Ground |
| Prop. 65 | Yes |
| Series | L581 |
| Shank Style | Straight Shank |
| Weight | 0.88 lbs. |
| Workpiece Material Range | Steel, Stainless Steel, Non-Ferrous, Cast Iron, Plastics |
| Country of Origin | JAPAN |
| Weight | 0.1 kg |
|---|---|
| Dimensions | 15 × 18 × 4 cm |
