Nachi 100% Original 94613 1/4"-20 Size, H5 Thread Limit, Bottoming Chamfer, 3 Flute, SG Coated Premium Cobalt / Vanadium High Speed Steel, Right Hand Cut Spiral Fluted Tap 1 pcs

Original price was: $17.78.Current price is: $8.89.

  • The breaking torque of SG spiral taps is 30% bigger than competitor, SGSP hardly breaks.
  • High flexibility for superior performance on a variety of materials, machines, and cutting conditions.
  • Achieves easy flow of chips while cutting on Stainless Steels, Structural Steels and Aluminum Alloys.
  • Coolant-free operation.
  • SG Taps series proved stable tapping in 304 stainless steel with minimal wear after 600 holes.
  • For tapping into pre-hardened die steels, mold steel and die steel (25-40 HRc).
  • Covers a wide range of applications - Aluminum, Cast Iron, Carbon Steel, Alloy Steel and Stainless Steel.
  • Made from premium cobalt / vanadium high speed steel material.
  • Modified bottoming style taps 2-1/2 to 3 thread lead.
  • Low spiral design with multilayer SG coating (TiN+TiCN) coating.
  • Optimized edge and flute shape allow for stable cutting threads, high rigidity and chip ejection.
  • Stable cutting threads and long tool life regardless of cutting speed.
  • Right-hand (clockwise) cutting direction.
  • Square shank with a smooth surface finishing.
  • ANSI Shank DIN Overall Length.
  • Available in three or four flutes design.
More Information
Brand NACHI
Tool Material Premium Cobalt / Vanadium High Speed Steel
Finish Coating SG Coated
Thread Size 1/4"-20
Cutting Direction Right Hand
Thread Length 0.433"
Overall Length 2-1/2"
Size Type ANSI
Thread Limit H5
Chamfer Style Bottoming
No. of Flutes 3
Shank Diameter 0.255"
Type SG Coated High Performance Low Spiral Bottoming Taps
Model # 94613
First Choice For: Steel
OC_Wood X
Prop. 65 Yes
Series L 6959
Size 1/4"
UNSPSC 23241615
Weight 0.05 lbs.
Workpiece Material Range Steel, Stainless Steel, High-Temp Exotic Alloys, Non-Ferrous, Cast Iron, Plastics
Country of Origin JAPAN
Weight 0.1 kg
Dimensions 15 × 18 × 4 cm
