Original Korloy CNMG431-MP NC3215 Carbide Turning Insert – Diamond 80° | Steel & More

Name: Original Korloy CNMG431-MP NC3215 Carbide Turning Insert - Diamond 80° | Steel &amp; More
Brand: Korloy
SKU: CNMG431-MP NC3215
Price: 17.83 USD
Availability: InStock
Rating: 4.6 (54 reviews)

Brand: Korloy

$17.83

★★★★⯨ 4.6 (54 reviews)

Buy original Korloy CNMG431-MP (CNMG431-MP NC3215) NC3215 Carbide Insert for steel, stainless steel, heat-resistant machining. Diamond coating. From $17.83. …

500 in stock

Need bulk pricing? Chat on WhatsApp

🚚Free worldwide shipping on all orders
⏱️Delivery in 15–30 days · express (DHL/FedEx) on request
🛃Free customs clearance handling & correct HS/NCM documents
💬Customer service replies within 24 hours, 7 days a week
✅100% genuine OEM — certificates available on request
🔒Guaranteed safe & secure checkout · 30-day money-back guarantee
📷Need test samples or real photos of this exact item? Just ask our team.

We accept

Verified on global marketplaces

Ozon★4.91,679 reviews · 5,188 ordersVerified store ↗AliExpress★4.898.9% positive · 4-year storeVerified store ↗Amazon★5.0Verified store ↗

Korloy CNMG431-MP NC3215 – Turning Carbide Insert

Specifications:
Subcategory: Indexable Inserts & Blades
Leaf Category: Turning & Boring Carbide Inserts
Brand: KORLOY
Model #: 1-02-057143
Tool Material: Carbide
Unit of Measure: Each
Inventory Status: Order as needed
Catalog Page: 9923
Grade: NC3215
Chipbreaker 3875: MP
Coating: CVD / TiCN+Al2O3+TiN
Insert IC: 1/2″
Insert Radius: 0.016″
Insert Shape & Angle: 80° Diamond
Insert Size: 431
Insert Style: CNMG
Insert Thickness: 3/16″
Relief Angle: 0°
Insert #: CNMG431-MP
Weight: 0.02 lbs.
Designation: CNMG431-MP NC3215

Industry references for Korloy CNMG431-MP: KORLOY 1-02-057143 – CNMG431-MP NC3215, 80° Diamond, Indexable Carbide Turning / Boring Insert Item # 22-290-322 Write a review Ask a question LP / MP Chip breakers have two step dots at the corner and bring measurable increase in productivity when machining forged steel at high speed (max. 350m/min) and high feed (max. .35mm/rev). NC3215 / NC3225 in combination with LP / MP en

Key Specifications

Brand	Korloy
Model	CNMG431-MP
Grade	NC3215
Coating	Diamond
Insert Shape	Diamond 80°
Clearance Angle	0°
Workpiece Materials	Steel, Stainless Steel, Heat-resistant
Application	Rough Machining
Geometry	Negative
Quantity	1 PCS

Grade NC3215 Characteristics

Korloy NC3215 uses Diamond coating tuned for rough machining on steel, stainless steel, heat-resistant. The chemistry favors edge stability under interrupted cutting and resists thermal cracking on longer passes.

Features & Benefits

100% Genuine Korloy – Original product with full quality guarantee, traceable batch.
Bulk Pricing Available – Discount tiers for production-volume orders; contact sales.
QC Inspected – Each batch sampled for edge profile, dimensional accuracy, and coating adhesion.
Diamond Coating – Superior wear resistance and extended tool life under continuous load.
Predictable Wear – Even flank wear pattern simplifies tool-life prediction and scheduling.
Optimized Chip Breaker – Engineered chip geometry reduces re-cutting and machine downtime.

Recommended Applications

Rough Machining of steel, stainless steel, heat-resistant in production CNC lines
Performs across a range of cutting speeds and feed rates
Suitable for both wet and dry machining conditions
CNC lathe and machining center compatible

Buying Considerations

Single-pack option — useful for prototype runs or qualification before bulk commitment. Entry-tier pricing makes this a low-risk option for trialing Korloy tooling on a new material.

Note: Compatible tool holders sold separately. Please confirm insert-holder seat compatibility (e.g. ISO seat designation) before ordering.

Weight	0.02 kg
Dimensions	15 × 18 × 4 cm

SKU: CNMG431-MP NC3215 Category: Insert Brand: Korloy
