Original Korloy VBMT331-MP NC9135 Carbide Turning Insert – Diamond 35° | Steel & More

Name: Original Korloy VBMT331-MP NC9135 Carbide Turning Insert - Diamond 35° | Steel &amp; More
Brand: Korloy
SKU: VBMT331-MP NC9135
Rating: 4.5 (19 reviews)

Brand: Korloy

$25.03

★★★★⯨ 4.5 (19 reviews)

Buy original Korloy VBMT331-MP (VBMT331-MP NC9135) NC9135 Carbide Insert for steel, stainless steel, heat-resistant machining. Diamond coating. From $25.03. …

500 in stock

Need a different quantity, brand or specification?Send us the part number — typical reply time: a few hours.

WhatsApp Inquiry ✉ Email 📞 +1 743 279 9499

🔒Guaranteed Safe & Secure Checkout
🚚Free shipping on orders over $99
↩️30-day money-back guarantee

We accept

Korloy VBMT331-MP NC9135 – Turning Carbide Insert

Specifications:
Subcategory: Indexable Inserts & Blades
Leaf Category: Turning & Boring Carbide Inserts
Brand: KORLOY
Model #: 1-02-061864
Tool Material: Carbide
Unit of Measure: Each
Inventory Status: Order as needed
Catalog Page: 9923
Grade: NC9135
Chipbreaker 3875: MP
Coating: CVD / TiCN+Al2O3+TiN
Insert IC: 3/8″
Insert Radius: 0.016″
Insert Shape & Angle: 35° Diamond
Insert Size: 331
Insert Style: VBMT
Insert Thickness: 3/16″
Relief Angle: 5°
Insert #: VBMT331-MP
Weight: 0.02 lbs.
Designation: VBMT331-MP NC9135

What machinists are saying about VBMT331-MP: KORLOY 1-02-057556 – VBMT331-MP NC3215, 35° Diamond, Indexable Carbide Turning / Boring Insert Item # 22-291-255 Write a review Ask a question LP / MP Chip breakers have two step dots at the corner and bring measurable increase in productivity when machining forged steel at high speed (max. 350m/min) and high feed (max. .35mm/rev). NC3215 / NC3225 in combination with LP / MP en

Key Specifications

Brand	Korloy
Model	VBMT331-MP
Grade	NC9135
Coating	Diamond
Insert Shape	Diamond 35°
Clearance Angle	5°
Workpiece Materials	Steel, Stainless Steel, Heat-resistant
Application	Finish Machining
Geometry	Chip breaker mp
Quantity	1 PCS

Grade NC9135 Performance Profile

Operators running steel, stainless steel, heat-resistant with the Korloy NC9135 typically report stable wear progression rather than catastrophic edge loss. The diamond system is the reason: it slows abrasion at the rake face while keeping the substrate from softening at the cutting zone.

Features & Benefits

100% Genuine Korloy – Original product with full quality guarantee, traceable batch.
Predictable Wear – Even flank wear pattern simplifies tool-life prediction and scheduling.
Diamond Coating – Superior wear resistance and extended tool life under continuous load.
Bulk Pricing Available – Discount tiers for production-volume orders; contact sales.
QC Inspected – Each batch sampled for edge profile, dimensional accuracy, and coating adhesion.
Optimized Chip Breaker – Engineered chip geometry reduces re-cutting and machine downtime.

Recommended Applications

Finish Machining of steel, stainless steel, heat-resistant in production CNC lines
Pairs well with through-coolant setups for chip evacuation
Holds dimensional tolerance over multiple indexings (insert)
Designed for shop conditions typical of Korloy tooling users worldwide

Buying Considerations

Single-pack option — useful for prototype runs or qualification before bulk commitment. Entry-tier pricing makes this a low-risk option for trialing Korloy tooling on a new material.

Reminder: Holder rigidity, lead angle, and approach all influence how this insert wears. Pair with a holder rated for the same cutting forces.

Weight	0.02 kg
Dimensions	15 × 18 × 4 cm

SKU: VBMT331-MP NC9135 Category: Insert Brand: Korloy
