Original Korloy VPGT220.5-VP1 PC5300 Carbide Turning Insert – Diamond 35° | Steel, Cast Iron

Name: Original Korloy VPGT220.5-VP1 PC5300 Carbide Turning Insert - Diamond 35° | Steel, Cast Iron
Brand: Korloy
SKU: VPGT220.5-VP1 PC5300
Rating: 4.6 (24 reviews)

Brand: Korloy

$27.27

★★★★⯨ 4.6 (24 reviews)

Buy original Korloy VPGT220.5-VP1 (VPGT220.5-VP1 PC5300) PC5300 Carbide Insert for steel, cast iron machining. Diamond coating. From $27.27. Free shipping. G…

500 in stock

Need a different quantity, brand or specification?Send us the part number — typical reply time: a few hours.

WhatsApp Inquiry ✉ Email 📞 +1 743 279 9499

🔒Guaranteed Safe & Secure Checkout
🚚Free shipping on orders over $99
↩️30-day money-back guarantee

We accept

Korloy VPGT220.5-VP1 PC5300 – Turning Carbide Insert

Specifications:
Subcategory: Indexable Inserts & Blades
Leaf Category: Turning & Boring Carbide Inserts
Brand: KORLOY
Model #: 1-02-043895
Tool Material: Carbide
Unit of Measure: Each
Inventory Status: Order as needed
Catalog Page: 9923
Grade: PC5300
Chipbreaker 3875: VP1
Coating: PVD / TiAlN
Insert IC: 1/4″
Insert Radius: 0.008″
Insert Shape & Angle: 35° Diamond
Insert Size: 220.5
Insert Style: VPGT
Insert Thickness: 1/8″
Relief Angle: 11°
Insert #: VPGT220.5-VP1
Weight: 0.010 lbs.
Designation: VPGT220.5-VP1 PC5300

Field reports & vendor notes: KORLOY 1-02-043895 – VPGT220.5-VP1 PC5300, 35° Diamond, Indexable Carbide Turning / Boring Insert Item # 22-289-312 Write a review Ask a question Travers Item #: 22-289-312 – KORLOY – VPGT220.5-VP1 PC5300, 35° Diamond, Indexable Carbide Turning / Boring Insert PC5300 Universal grade for stainless, HRSA, steel and interrupted cast iron machining High chipping and welding resista

Key Specifications

Brand	Korloy
Model	VPGT220.5-VP1
Grade	PC5300
Coating	Diamond
Insert Shape	Diamond 35°
Clearance Angle	11°
Workpiece Materials	Steel, Cast Iron
Application	Finish Machining
Geometry	Negative
Quantity	1 PCS

Grade PC5300 Characteristics

Korloy PC5300 uses Diamond coating tuned for finish machining on steel, cast iron. The chemistry favors edge stability under interrupted cutting and resists thermal cracking on longer passes.

Features & Benefits

100% Genuine Korloy – Original product with full quality guarantee, traceable batch.
QC Inspected – Each batch sampled for edge profile, dimensional accuracy, and coating adhesion.
Bulk Pricing Available – Discount tiers for production-volume orders; contact sales.
Diamond Coating – Superior wear resistance and extended tool life under continuous load.
Predictable Wear – Even flank wear pattern simplifies tool-life prediction and scheduling.
Optimized Chip Breaker – Engineered chip geometry reduces re-cutting and machine downtime.

Recommended Applications

Finish Machining of steel, cast iron in production CNC lines
Useful for batch production where tool-life predictability matters
Performs across a range of cutting speeds and feed rates
Suitable for both wet and dry machining conditions

Buying Considerations

Single-pack option — useful for prototype runs or qualification before bulk commitment. Entry-tier pricing makes this a low-risk option for trialing Korloy tooling on a new material.

Note: Compatible tool holders sold separately. Please confirm insert-holder seat compatibility (e.g. ISO seat designation) before ordering.

Weight	0.01 kg
Dimensions	15 × 18 × 4 cm

SKU: VPGT220.5-VP1 PC5300 Category: Insert Brand: Korloy
