Nachi 100% Original 1455778 3/4 180° Solid Carbide Flat Bottom High Performance Drill 1 pcs

Nachi 100% Original 0713610 8.10mm 180° Solid Carbide Flat Bottom High Performance Drill 1 pcs

Name: Nachi 100% Original 0713610 8.10mm 180&#176; Solid Carbide Flat Bottom High Performance Drill 1 pcs
Brand: Nachi
SKU: 713610
Rating: 4.7 (28 reviews)

Brand: Nachi

$18.05

★★★★⯨ 4.7 (28 reviews)

Need a different quantity, brand or specification?Send us the part number — typical reply time: a few hours.

WhatsApp Inquiry ✉ Email 📞 +1 743 279 9499

🔒Guaranteed Safe & Secure Checkout
🚚Free shipping on orders over $99
↩️30-day money-back guarantee

We accept

More Information
Brand	NACHI
Size Type	Metric
Size	8.10mm
Drill Point Angle	180°
Tool Material	Solid Carbide
Finish Coating	Aqua EX TiAIN + AlTiCR
Shank Diameter	8.00mm
Overall Length	80.00MM
Type	Flat Bottom Drill
Flute Length	37mm
Cutting Direction	Right Hand
First Choice For:	High Temp Exotic Alloys
Model #	0713610
Helix Angle	20°
Cutting Diameter	8.1mm
Decimal Size	.3189"
Drill Type	Flat Bottom
Effective Length	40mm
Flute Shape	Spiral
Helix Direction	Right Hand
Hole Depth	3xD
No. of Flutes	2
Prop. 65	Yes
Series	L9610
Shank Style	Straight Shank
Single or Double End	Single
Tolerance_Cutting Diameter	+0/-.0006"
Weight	0.10904226591849639
Workpiece Material	Structural Steels, Carbon Steels, Cast Irons, Alloy Steels, Heat Treated Steels, Hardened Steels, Stainless steels, Aluminum Alloys, Aluminum Castings
Workpiece Material Range	Steel, Stainless Steel, High-Temp Exotic Alloys, Non-Ferrous, Cast Iron, Hard Materials
Country of Origin	JAPAN
Shipping Restrictions	UPS Ship (drop ship item)

Weight	0.1 kg
Dimensions	15 × 18 × 4 cm

SKU: 713610 Category: Others Brand: Nachi

Related products

Nachi 100% Original 0721603 11.50mm 180° Solid Carbide Flat Bottom High Performance Drill 1 pcs
$41.15
One drill does it all-eliminates the need to use a center drill or end mill on inclined or curved surfaces.

Self lubricating AQUA EX coating offers superior resistance.

Ideal for flat bottom applications in the oil & gas, automotive as well as general industries.

True 180° flat cuttung edges creates minimal exit burr in tubing & thin plates.

Improved heat & wear resistance with our AQUA EX Coating (TiAlN + AlTiCR).

Ideal for counterboring, angled holes & intersecting holes.

Double margin & corner chamfer for added stability & tool life.
Add to cart
Nachi 100% Original 1058370 9/16 Size, 2MT 118° High Speed Steel Taper Shank Drill 1 pcs
$76.20
Used for deep hole drilling with Taper Shank
Add to cart
Nachi 100% Original 0011125 #57 118° High Speed Steel Jobbers Drill 1 pcs
$0.37
Right hand (clockwise rotation) cutting direction.

Standard two flute design.

Standard spiral, helical flutes.
Add to cart
Nachi 100% Original 0697501 5.56mm Size 135° Powdered Metal Cobalt Screw Machine Length Stub Drill 1 pcs
$9.21
This drill having stub length is suited for high-speed drilling and precise positioning and diameter.

This is useful in material from Carbon Steels and Stainless Steels to Aluminum.

PM-HSS SG Coated

Range 1.0mm to 20.0mm

Metric Sizes.
Add to cart

Cart

Latest Arrivals

Why Hooguu Tools

Nachi 100% Original 0713610 8.10mm 180° Solid Carbide Flat Bottom High Performance Drill 1 pcs

Shop by Brand

CNC Knowledge Hub

Cart

Cart

Latest Arrivals

Why Hooguu Tools

Nachi 100% Original 0713610 8.10mm 180° Solid Carbide Flat Bottom High Performance Drill 1 pcs

Shop by Brand

CNC Knowledge Hub

Cart

Original TaeguTec TT8105B Carbide Insert - Triangle (10 PCS) XNMG 110504 FGP XNMG 110504 FGP TT8105B
