Nachi 100% Original 1455778 3/4 180° Solid Carbide Flat Bottom High Performance Drill 1 pcs

Nachi 100% Original 0713706 9.30mm 180° Solid Carbide Flat Bottom High Performance Drill 1 pcs

Name: Nachi 100% Original 0713706 9.30mm 180&#176; Solid Carbide Flat Bottom High Performance Drill 1 pcs
Brand: Nachi
SKU: 713706
Rating: 4.9 (19 reviews)

Brand: Nachi

$20.17

★★★★⯨ 4.9 (19 reviews)

Need a different quantity, brand or specification?Send us the part number — typical reply time: a few hours.

WhatsApp Inquiry ✉ Email 📞 +1 743 279 9499

🔒Guaranteed Safe & Secure Checkout
🚚Free shipping on orders over $99
↩️30-day money-back guarantee

We accept

More Information
Brand	NACHI
Size Type	Metric
Size	9.30mm
Drill Point Angle	180°
Tool Material	Solid Carbide
Finish Coating	Aqua EX TiAIN + AlTiCR
Shank Diameter	8.00mm
Overall Length	80.00MM
Type	Flat Bottom Drill
Flute Length	43mm
Cutting Direction	Right Hand
First Choice For:	High Temp Exotic Alloys
Model #	0713706
Helix Angle	20°
Cutting Diameter	9.3mm
Decimal Size	.3661"
Drill Type	Flat Bottom
Effective Length	45mm
Flute Shape	Spiral
Helix Direction	Right Hand
Hole Depth	3xD
No. of Flutes	2
Prop. 65	Yes
Series	L9610
Shank Style	Straight Shank
Single or Double End	Single
Tolerance_Cutting Diameter	+0/-.0006"
Weight	0.11835875383150074
Workpiece Material	Structural Steels, Carbon Steels, Cast Irons, Alloy Steels, Heat Treated Steels, Hardened Steels, Stainless steels, Aluminum Alloys, Aluminum Castings
Workpiece Material Range	Steel, Stainless Steel, High-Temp Exotic Alloys, Non-Ferrous, Cast Iron, Hard Materials
Country of Origin	JAPAN
Shipping Restrictions	UPS Ship (drop ship item)

Weight	0.1 kg
Dimensions	15 × 18 × 4 cm

SKU: 713706 Category: Others Brand: Nachi
