Nachi 100% Original 0722324 7.00mm 135° Powdered Metal HSCO Steel Jobbers Drill 1 pcs

Name: Nachi 100% Original 0722324 7.00mm 135&#176; Powdered Metal HSCO Steel Jobbers Drill 1 pcs
Brand: Nachi
SKU: 722324
Rating: 4.5 (14 reviews)

Brand: Nachi

$11.53

★★★★⯨ 4.5 (14 reviews)

4-Facet self-centering point.
Made from premium powdered metal cobalt substrate.
Composite Multi-layer SG Coating (Tin+TiCN).
Precision ground end mill style shank for accurate and precision drilling.

Need a different quantity, brand or specification?Send us the part number — typical reply time: a few hours.

WhatsApp Inquiry ✉ Email 📞 +1 743 279 9499

🔒Guaranteed Safe & Secure Checkout
🚚Free shipping on orders over $99
↩️30-day money-back guarantee

We accept

More Information
Brand	NACHI
Size Type	Metric
Size	7.00mm
Drill Point Angle	135°
Tool Material	Powdered Metal HSCO Steel
Finish Coating	Tin+TiCN Coated
Shank Diameter	8.00mm
Overall Length	113.00mm
Flute Length	69mm
Cutting Direction	Right Hand
Model #	0722324
Point Sharpening Type	Split Point
Helix Angle	Conventional Spiral
Package Qty	1
Application	Holemaking
No. of Flutes	2
Prop. 65	Yes
Series	L7574P
UNSPSC	23241634
Weight	0.06886 lbs.
Workpiece Material	Stainless Steel, Carbon Steel, Alloy Steel, Aluminum, Cast Irons
Country of Origin	JAPAN
Shipping Restrictions	UPS Ship (drop ship item)

Weight	0.1 kg
Dimensions	15 × 18 × 4 cm

SKU: 722324 Category: Others Brand: Nachi
