Zcc.ct 100% Original KIT2-ZTD03-06-02 – ZTD Multi-Point Holder Set with Inserts, 3XD Drill Length Ratio 1 pcs Holder:ZTD03-1.25-XP1.25-SP09-02
Original price was: $126.99.$63.49Current price is: $63.49.
- Utilizes four cornered SPGT inserts.
- Large flute gullets for chip evacuation
- Coolant thru helical flutes helps extend tool life and remove chips
- Screw on system for less chip interference.
- Indexable drills do not need a center drill before application
- Utilizes four cornered drilling inserts.
- Inserts available in multiple grades and geometries.
- Coolant thru capable.
- Very strong and durable drill bodies for higher feed rates.
- Suitable for multiple materials.
- (1) Indexable Drill.
- (10) Center Inserts.
- (10) Peripheral Inserts
- (1) Torx® wrench.
- (1) Lubricating Grease.
- Product literature.
- Fitted case for convenience and storage.
- PM chip breaker recommended for Steels and Cast Irons.
- EM chip breaker recommended for Stainless Steels and Non-Ferrous materials.
- YBG205 grade for peripheral inserts.
- YBG212 grade for center inserts.
| Brand | ZCC-CT |
|---|---|
| Series | ZTD |
| Drill Diameter X Length Ratio | 3XD |
| Maximum Depth of Cut | 3.950" |
| Shank Diameter | 1.250" |
| Drill Diameter | 1.250" |
| Holder | ZTD03-1.25"-XP1.25"-SP09-02 |
| Use Insert # | SPGT090408 |
| Overall Length | 7.290" |
| Coolant Use | Yes |
| Central Insert | SPGT090408 |
| Designation | ZTD03-1.25"-XP1.25"-SP09-02-EMYBG212 |
| Model # | KIT2-ZTD03-06-02 |
| No. of Inserts | 2 |
| Peripheral Insert | SPGT090408 |
| Prop. 65 | Yes |
| Use Torx Key # | T-15 |
| Use Torx Screw # | I60M3.5X8 |
| Weight | 2.986 lbs. |
| Country of Origin | IMPORT |
| Shipping Restrictions | UPS Ship (drop ship item) |
| Weight | 0.1 kg |
|---|---|
| Dimensions | 15 × 18 × 4 cm |
