ZCC-CT TCMT110204-HM YBC151 Triangle Steel TCMT211

Name: ZCC-CT TCMT110204-HM YBC151 Triangle Steel TCMT211
Brand: ZCC-CT
SKU: TCMT110204-HM YBC151
Price: 63.14 USD
Availability: PreOrder

Brand: ZCC-CT

$63.14

The ZCC-CT TCMT110204 is a professional-grade carbide insert designed for carbon and alloy steel turning. Suitable for CNC lathes with appropriate tool holders. Recommended Vc 200-350 m/min roughing, 300-450 m/min finishing. Use through-coolant or high-pressure coolant for optimal results. Available from Hooguu.com with worldwide shipping and competitive pricing. SKU: TCMT110204-HM YBC151.

500 in stock

ⓘ Prices move with raw-material (tungsten / steel) market rates. Please confirm the current price with us before placing your order — thank you.

Confirm price / bulk pricing on WhatsApp

🚚Free worldwide shipping on all orders
⏱️Delivery in 15–30 days · express (DHL/FedEx) on request
🛃Free customs clearance handling & correct HS/NCM documents
💬Customer service replies within 24 hours, 7 days a week
✅100% genuine OEM — certificates available on request
🔒Guaranteed safe & secure checkout · 30-day money-back guarantee
📷Need test samples or real photos of this exact item? Just ask our team.

We accept

Verified on global marketplaces

Ozon★4.91,679 reviews · 5,188 ordersVerified store ↗AliExpress★4.898.9% positive · 4-year storeVerified store ↗Amazon US★5.0Verified store ↗

Specifications
Brand	ZCC-CT
Part No. (MPN)	TCMT110204-HM
Grade	YBC151
Shape	Triangle
Suitable Material	Steel
Category	Triangle (TNMG)

ZCC-CT TCMT110204-HM YBC151 – Turning Carbide Insert

ZCC.CT TCMT110204-HM YBC151 Turning Insert Premium CVD Coated Carbide for High-Speed Steel Machining Product Overview “Which carbide insert grade is best for achieving high surface finish on carbon steel and alloy steel at high cutting speeds?” The ZCC.CT TCMT110204-HM YBC151 is a high-performance triangular turning insert optimized for ISO P (Steel) materials. The YBC151 grade features a thick Al2O3 CVD coating combined with a high-strength substrate, making it the industry standard for finishing to semi-finishing applications. Its -HM chipbreaker geometry is specifically designed to handle medium feed rates, ensuring excellent chip evacuation and reducing heat build-up on the workpiece. Core Performance Features High Wear Resistance: Thick CVD coating layer extends tool life during continuous high-speed turning. Precision HM Geometry: Optimized chip-breaker for stable chip control across a wide range of feed rates. Fine Surface Finish: Engineered to provide smooth finishes on alloy steels, reducing the need for secondary grinding. Technical Specifications ISO Model Decoding TShape CClearance MTolerance TFeature 11Size 02Thk 04Radius HMChip Standard Model Designation Metric (ISO) TCMT110204-HM Imperial (ANSI) TCMT21.51-HM Recommended Parameters Workpiece Material Cutting Speed (Vc) Feed Rate (f) Carbon Steel 200 – 400 m/min 0.10 – 0.25 mm/rev Alloy Steel 150 – 350 m/min 0.08 – 0.20 mm/rev Required Tool Holder: Compatible STGCR/L Holders > Applications High-speed finishing of automotive components. Precision machining of alloy steel shaft parts. Semi-finishing of general carbon steel structural parts. Compatibility This insert fits all standard ISO-compliant external turning holders and internal boring bars that support the TCMT 1102 (21.5) pocket size. ZCC.CT Steel Grade Matrix Grade Coating Application YBC151 (Current) CVD Finishing / High Speed YBC251 CVD Semi-Finishing / General Purpose YBC351 CVD Roughing / Interrupted Cuts Global Customer Feedback ★★★★★”Exceptional Finishing” I used these on 4140 steel. The surface finish is mirror-like. Very impressed with the YBC151 grade durability. — Mark S., USA 🇺🇸 ★★★★★”Ottima qualità” Inserti molto affidabili per lavorazioni ad alta velocità. Rapporto qualità-prezzo imbattibile. — Roberto F., Italy 🇮🇹 ★★★★☆”Reliable Performance” Great chip control. The HM breaker works perfectly even at lower feeds. — Kenji H., Japan 🇯🇵 Professional CNC FAQ Q: Can I use YBC151 for interrupted cutting? A: YBC151 is a hard grade optimized for continuous high-speed finishing. For heavy interrupted cuts, we recommend using the tougher YBC351 grade. Q: What is the difference between YBC151 and YBC251? A: YBC151 has higher wear resistance for high speeds, whereas YBC251 offers a better balance of toughness and wear resistance for general steel turning. Equivalent Models Sandvik: TCMT110204-PF | Kennametal: TCMT110204-FP | Mitsubishi: TCMT110204-FP Workpiece Material Matrix Steel (P): ● Excellent | Stainless (M): ○ Acceptable | Cast Iron (K): △ Not Recommended Troubleshooting: Excessive flank wear? Reduce cutting speed. Edge chipping? Switch to a tougher grade like YBC251.

Key Specifications

Brand	ZCC-CT
Model	TCMT110204-HM
Grade	YBC151
Coating	Al2O3
Insert Shape	Triangle
Clearance Angle	7°
IC (Inscribed Circle)	11mm
Thickness	0.2mm
Nose Radius	0.4mm
Workpiece Materials	Steel, Cast Iron
Application	Finish Machining
Geometry	Positive
Quantity	1 PCS

Features & Benefits

100% Genuine ZCC-CT – Original product with full quality guarantee, traceable batch.
Thermal Resistance – al2o3 layer holds hardness above typical cutting-zone temperatures.
Edge Stability – Substrate chemistry tuned to limit micro-chipping on steel, cast iron interruptions.
Professional CNC Tooling – Compatible with major CNC machine brands (Mazak, DMG, Haas, Doosan).
Al2O3 Coating – Superior wear resistance and extended tool life under continuous load.
Optimized Chip Breaker – Engineered chip geometry reduces re-cutting and machine downtime.

Recommended Applications

Finish Machining of steel, cast iron in production CNC lines
Designed for shop conditions typical of ZCC-CT tooling users worldwide
Holds dimensional tolerance over multiple indexings (insert)
Pairs well with through-coolant setups for chip evacuation

Buying Considerations

Single-pack option — useful for prototype runs or qualification before bulk commitment. Mid-tier pricing reflects ZCC-CT’s production-grade tolerances rather than economy substrate.

Note: Compatible tool holders sold separately. Please confirm insert-holder seat compatibility (e.g. ISO seat designation) before ordering.

Weight	0.2 kg
Dimensions	15 × 18 × 4 cm

What Buyers Say

★★★★★

100% recomendados los insertos, y el paquete está llegando muy rapido

Lizeth Villasana Rosales, Mexico via aliexpress

★★★★★

Товар доставлен, оригинальный, упаковка отличная! Всё полностью соответствует описанию.

YUrij S., Russia via Ozon

★★★★★

По сырой стали пойдёт. Большой радиус при вершине, больше нагрузка.

Vladimir G., Russia via Ozon

★★★★★

A good product and the seller offered a nice discount

Michael, American via Amazon

★★★★★

the product is like show in the picture

Jose, American via Amazon

★★★★★

дошло быстрее чем заявлено. все супер

Mariya R., Russia via Ozon

SKU: TCMT110204-HM YBC151 Categories: Insert, Turning Inserts, Triangle (TNMG) Tag: ZCC.CT Brand: ZCC-CT
